SSH-Coil Splitting Loaded Pickguard with Two Mini Humbuckers - Pearl

In this review the MAXCHEER SSH-Coil Splitting Loaded Pickguard is examined from the perspective of a player seeking high output and tonal flexibility without a full pickup swap. The bottom line: this prewired pearl white pickguard is for guitarists who want plug-and-play coil splitting and a fat, ceramic-driven tone from two mini humbuckers plus a higher-output 4-coil bridge configuration. It delivers a range of sounds thanks to a 5-way selector and three on/on coil split switches, while requiring only minor routing or screw-hole adjustments on many instruments.

Key Features

• Prewired Loaded Pickguard: Arrives with volume and two tone pots plus a 5-way switch already wired, so installation is faster than building from parts.
• Coil Split Flexibility: Three two-way on/on switches let the player split individual pickups for single-coil-like tone or combine full humbucker output for thicker sound.
• Ceramic Magnet Pickups: Ceramic magnets provide a focused, high-output character that works well for overdrive and rock styles.
• Four-Conductor Wiring: Red and white leads allow coil splitting while black is hot and green is ground, making further wiring changes straightforward for technicians.
• Pearl White PVC Pickguard: 3-ply PVC surface with thin protective film keeps the appearance clean until installation.
• Compact Form Factor: Two mini humbuckers plus a 4-coil bridge occupy a standard loaded pickguard footprint, useful for players who want more output without replacing the body or control cavity.

Who It's For

This loaded pickguard suits players upgrading an S-style guitar who want high output and tonal variety without soldering every connection; the prewired controls make it appealing to hobbyists and gigging musicians who need fast install. It is also useful for modders who like the option to rewire later thanks to four-conductor pickup leads and accessible switches.

Players who need exact factory hole alignment or a different pickup spacing should be cautious, as the pickguard may require slight modification for some guitars. Those wanting vintage-voiced alnico pickups or lower DC resistance single-coil tone should look elsewhere, since these pickups use ceramic magnets and higher resistance values.

Pros & Cons

Pros

• Prewired layout with one volume and two tone controls reduces installation time for most hobbyist installs.
• Coil splitting via three on/on switches offers extensive tonal options from humbucker thickness to spanky single-coil tones.
• High DC resistance values (9K neck/middle, 18K bridge) deliver a powerful output suited to drive pedals and amps.
• Pearl white 3-ply pickguard gives a clean, finished look with protective film to prevent scratches before fitting.

Cons

• May require slight modification for exact screw-hole alignment on nonstandard guitars.
• Ceramic magnet, high-resistance pickups will not mimic vintage alnico single-coil character exactly.

Specifications

Pickguard Color	Pearl White 3-ply PVC
Pickup Configuration	Two mini humbuckers + one 4-coil bridge
Pickup Magnet	Ceramic
D.C. Resistance	Neck/Middle 9K (split 4.5K), Bridge 18K (split 9K)
Controls	1 volume, 2 tone, 5-way switch, 3 two-way on/on coil split switches
Wiring	Four-conductor (black hot, green ground, red/white coil split)
Screw Holes	11 (may need adjustment for some guitars)

Our Verdict

The MAXCHEER SSH-Coil Splitting Loaded Pickguard is a practical, cost-effective upgrade for players seeking high output and broad tonal control without a full pickup swap. It is especially good value for those who appreciate prewired convenience and coil split options, though players after vintage alnico warmth or perfect factory hole alignment should consider alternatives.

Frequently Asked Questions

Can I split each pickup independently?
Yes. The pickguard includes three two-way on/on switches so each pickup can be split independently to access single-coil tones.

Will this fit my S-style guitar without modification?
Many S-style guitars are compatible, but some models have different hole patterns so minor modification may be necessary for exact alignment.

What are the pickup resistance values?
The neck and middle read 9K each (split to 4.5K), and the bridge is 18K (split to 9K), indicating a high-output ceramic character.
